Product Description
SALIENT FEATURES :
- '0' Ring Type Construction
- 3 Size 3", 5" & 10" Between Bolt Centers
- For Non Pressurised Tanks Only
- Can Be Mounted On Tapped Holes
- Suitable For Mineral / Petroleum Based Oils
- Maximum Temperature 80C
MODEL | A | B | C | D | E | WT |
KGS |
OLI-03 | 75.8 | 37 | 20 | 35 | 108 | 0.16 |
OL1-05 | 127 | 69.5 | 20 | 35 | 157.5 | 0.18 |
OU-10 | 254 | 203 | 20 | 35 | 160 | 0.28 |
Model Code : Assembly
OLI |
| -5 | T |
SERIES |
| SIZE | FEATURE |
INCH | OPTIONAL # |
OLI |
| 03 - 3" | T - THERMOMETER (OMIT IF MOT REQD) |
05-5 |
10-10 |
OPTIONAL / SPECIAL FEATURE - OMIT IF NOT REQUIRED
- COVER
- INDICATOR
- TUBE
- '0' RING (ID 14 x 2.5 CSD)
- END PIECE
- BOLTM12
- 0' RING (ID 12 x 2.5 CSD]
- NUT
- WASHER (ID 12.5 x OD 27 x 3 CSD)
- TANKWALL
- THERMOMETER (OPTIONAL)
Reliable Oil Monitoring for IndustriesThe OLI Face Type Oil Level Indicator ensures dependable oil level monitoring, simplifying maintenance tasks and helping prevent machinery breakdowns. Its accuracy and robust construction make it ideal for heavy-duty industrial applications where reliable fluid control is critical.
Built for Industrial DemandsConstructed from high-grade metal, the indicator withstands demanding environments and operates efficiently within industry-standard temperature ranges. Its high quality and resilience guarantee consistent performance, even during continuous operations.
FAQs of OLI Face Type Oil Level Indicator:
Q: How does the OLI Face Type Oil Level Indicator function in industrial applications?
A: The indicator works by providing a clear visual display of oil levels in reservoirs, tanks, or systems, ensuring operators can easily track and maintain optimal oil levels, thereby safeguarding equipment performance.
Q: What industries commonly use the OLI Face Type Oil Level Indicator?
A: This indicator is widely used across various industries including manufacturing, power generation, automotive, and hydraulic equipment sectors due to its accuracy and durability.
Q: When should I use this oil level indicator in my machinery?
A: You should use the OLI Face Type Oil Level Indicator whenever precise oil monitoring is critical, such as during equipment startup, routine checks, or preventative maintenance to avoid lubrication failures.
Q: Where can this device be installed for optimal usage?
A: The indicator can be mounted on oil tanks, gearboxes, hydraulic reservoirs, or any equipment requiring constant oil level monitoring. Installation should follow manufacturer guidelines for safety and accuracy.
Q: What benefits does this oil level indicator offer compared to standard models?
A: It offers 100% accuracy, high-quality materials, and reliable readings even under harsh industrial conditions, reducing maintenance costs and preventing equipment downtime.
Q: How is the installation process carried out for this indicator?
A: Typically, installation involves mounting the indicator to the designated oil reservoir or tank using standard fittings, ensuring a secure and leak-proof connection. Detailed instructions are provided by the manufacturer.
Q: Does the OLI Face Type Oil Level Indicator come with a warranty?
A: Yes, this product is supplied with a warranty, providing assurance against manufacturing defects and ensuring customer confidence in its long-term reliability.
