Bulkhead Elbow-WSV

Get a Price/Quote

Product Details:

Tolerance 0.02 mm
Thread Type BSPT, BSP, NPT (as required)
Bend Radius 90
Temperature Range -20C to 120C
Flexibility Rigid
Diameter 6 mm, 8 mm, 10 mm, 12 mm (Custom sizes available)
Sealing Type Metal-to-Metal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Bulkhead Elbow-WSV Product Specifications

Bend Radius 90
Connection Compression or Threaded
Thread Type BSPT, BSP, NPT (as required)
Color Golden/Silver (Nickel Finish)
Tolerance 0.02 mm
Surface Treatment Nickel Plated
Material Brass
Flexibility Rigid
Temperature Range -20C to 120C
Rated Pressure Up to 16 Bar (232 psi)
Material Grade CW614N / C36000 (Brass)
Usage Pneumatic, Hydraulic, Instrumentation Line Fittings
Shape Elbow (90) with Bulkhead
Coating Type Nickel Coated
Tensile Strength > 340 MPa
Application Industrial Gas, Oil, Liquid Transfer Lines
Sealing Type Metal-to-Metal
Outer Diameter 6 mm to 20 mm (Options available)
Diameter 6 mm, 8 mm, 10 mm, 12 mm (Custom sizes available)
Product Type Bulkhead Elbow-WSV
Length Varies by model, typically 35 mm - 70 mm
Connection Type Bulkhead & Elbow
Section Shape Round
Standard DIN, ISO, or custom
Yield Strength > 190 MPa
Thickness 4 mm (Typical) or as per specification

Installation Panel Mounted
Leakage Test 100% factory tested
Suitable Media Air, Water, Oil, Non-aggressive Fluids
Package Type Individual Polybag or Boxed
Corrosion Resistance High
Customization Available for thread, size, and coating
Fitting Method Push-in / Threaded coupling

Bulkhead Elbow-WSV Trade Information

Supply Ability 5000 Per Month
Delivery Time 10 Days

Product Description

Utilise this outstanding Bulkhead Elbow-WSV to capitalise on masterful engineering and sought-after reliability for your fluid handling requirements. Robustly manufactured in high-grade CW614N/C36000 brass and finished with a corrosion-resistant nickel coating, this elbow is designed for enduring performance in harsh industrial settings. Each unit is 100% factory leakage-tested, offering superior dependability for pneumatic, hydraulic, and instrumentation line fittings. Flexibility in thread, size, and coating customisation ensures optimal integration. Supplied in secure individual polybags or boxes, this product is a trusted offer for manufacturers, suppliers, and traders across India.

Versatility and Material Excellence for Industrial Plants

Bulkhead Elbow-WSV features a high-grade nickel-plated brass body designed for outstanding corrosion resistance in various plant applications. Its surface adapts seamlessly to industrial environments, including oil, gas, pneumatic, or hydraulic lines. With a precise tolerance of 0.02 mm and a thickness of 4 mm, it is masterfully suited for rigorous usage, providing long-lasting performance. The sturdy material ensures secure and leak-free operation, making it ideal for critical connections across a range of industries.

Bulkhead Elbow-WSV Sample Availability and Delivery Protocol

We offer Bulkhead Elbow-WSV samples to assist domestic market clients in product evaluation and optimal selection. Samples are dispatched from our FOB port, with transparent delivery and handover mechanisms in place for efficient logistics. Our sample policy ensures minimal hassle-request a unit, assess it on your site, and confirm its compatibility before making larger commitments. This streamlined process empowers you to capitalise on reliability and quality right from the start.

FAQ's of Bulkhead Elbow-WSV:

Q: How does the Bulkhead Elbow-WSV ensure leak-proof performance?

A: The Bulkhead Elbow-WSV undergoes 100% factory leakage testing, features precise metal-to-metal sealing, and is manufactured from corrosion-resistant, nickel-plated brass-ensuring an outstanding, leak-proof connection even under challenging conditions.

Q: What customisation options are available for the Bulkhead Elbow-WSV?

A: Customers can request the Bulkhead Elbow-WSV in different thread types (BSPT, BSP, NPT), diameters, sizes, and coatings. Custom configurations for material grade and coatings are also available according to project requirements.

Q: Where can Bulkhead Elbow-WSV be utilised most effectively?

A: This fitting is masterfully suited for use in industrial gas, oil, and liquid transfer lines, as well as pneumatic, hydraulic, and instrumentation applications across manufacturing plants and processing facilities.

Q: What media is the Bulkhead Elbow-WSV suitable for?

A: The fitting is designed to handle air, water, oil, and non-aggressive fluids with high efficiency, making it a versatile choice for varied applications.

Q: What is the benefit of the push-in/threaded coupling method?

A: The dual push-in/threaded coupling boosts installation flexibility and shortens assembly time while maintaining rigid, dependable connections for increased operational productivity.
