WSV Elbow Bulkhead Couplings

Get a Price/Quote

Product Details:

Connection Type Bulkhead with Elbow
Tensile Strength >=520 MPa (for SS316)
Thread Type BSP / NPT / Metric / UNF
Flexibility Rigid
Coating Type Nickel / Zinc / Chrome (Optional)
Diameter 6 mm, 8 mm, 12 mm, 16 mm (others on request)
Yield Strength >=210 MPa (for SS316)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

WSV Elbow Bulkhead Couplings Product Specifications

Outer Diameter 6 mm - 38 mm
Tensile Strength >=520 MPa (for SS316)
Connection Type Bulkhead with Elbow
Length 30 mm - 120 mm
Surface Treatment Nickel Plated / Zinc Plated / Polished
Yield Strength >=210 MPa (for SS316)
Diameter 6 mm, 8 mm, 12 mm, 16 mm (others on request)
Tolerance 0.05 mm
Material Grade SS304 / SS316 / CW617N (Brass) / ASTM A105 (Carbon Steel)
Thread Type BSP / NPT / Metric / UNF
Color Metallic Silver / Yellowish / Custom Coating
Material Stainless Steel / Brass / Carbon Steel
Connection Threaded
Coating Type Nickel / Zinc / Chrome (Optional)
Product Type Elbow Bulkhead Coupling
Flexibility Rigid
Section Shape Round
Rated Pressure Up to 6000 PSI (414 Bar)
Shape Elbow (90)
Bend Radius 90
Thickness 1.5 mm - 6 mm (As per design)
Application Pipe connection, flow control, panel / wall mounting
Sealing Type Metal-to-metal or O-ring (on request)
Temperature Range -40C to +250C
Usage Hydraulic, pneumatic & instrumentation systems
Standard DIN / ISO / ASTM / JIS

Operating Media Oil, Water, Gas, Air, Chemical Fluids
Customisation Available (Material, Size, Coating)
Weight As per size and material
Testing Hydrostatic, Pneumatic, and Leak Test
Corrosion Resistance Excellent (SS304 / SS316); Good (Brass/Zinc)
Pressure Range Up to 400 Bar (in general application)
Installation Bulkhead mounting with lock nut
Leak Proof Design Yes, precision engineered
Packing Type Box / Polybag / Customized
Minimum Order Quantity 50 Pieces
Thread Size Range 1/8" to 1" (other sizes on request)
Compatibility Suitable for various industrial piping systems

WSV Elbow Bulkhead Couplings Trade Information

Supply Ability 5000 Per Month
Delivery Time 10 Days

Product Description

Experience prodigious performance with WSV Elbow Bulkhead Couplings, now available at a special rate. Crafted for unassailable durability and fresh reliability, these precision-engineered couplings support a pressure range up to 400 Bar and provide excellent corrosion resistance in SS304/SS316 material grades. The highlighted leak-proof design, coupled with valuable flexibility in materials and coatings, ensures seamless compatibility across diverse industrial piping systems. Customisation on size, coating, or material is available, making these couplings a shining solution for demanding hydraulic, pneumatic, and instrumentation applications.

Robust Utility and Premium Material Diversity

WSV Elbow Bulkhead Couplings feature an elbow (90) design, crafted from stainless steel, brass, or carbon steel for prodigious material performance. The couplings are suitable for high-pressure hydraulic and pneumatic systems, ensuring unassailable operational reliability. Their metallic surfaces-ranging from polished to custom-coated finishes-guarantee compatibility with various application surfaces, offering both durability and a professional appearance in any environment.

Efficient Delivery, Packaging, and Sample Options

We offer reliable transportation and supply services for WSV Elbow Bulkhead Couplings, with estimated delivery timelines tailored to your project needs. Products are securely packaged in boxes, polybags, or customized containers to ensure impeccable condition on arrival. Sample units are available for those requiring evaluation prior to bulk orders, ensuring informed decision-making and smooth procurement processes for every customer.

FAQ's of WSV Elbow Bulkhead Couplings:

Q: How do I install the WSV Elbow Bulkhead Couplings for my piping system?

A: Installation is straightforward due to their bulkhead mounting design, which uses a lock nut for secure and leak proof connections. Simply follow the provided guidelines to ensure proper threading and sealing.

Q: What materials are available for these couplings, and how do I choose the right one for my application?

A: WSV couplings are available in stainless steel (SS304/SS316), brass, or carbon steel. Selection depends on your media, environmental conditions, and required corrosion resistance. Our specialists can help you determine the right option.

Q: When should I consider customising the couplings (size, material, or coating)?

A: Custom options are ideal when your application requires specific dimensions, materials, or enhanced surface protection. Customisation ensures perfect fit and peak performance for unique system requirements.

Q: Where are these couplings typically used?

A: These couplings are used in hydraulic, pneumatic, and instrumentation systems-perfect for industrial pipes, flow control operations, and panel or wall mounting in demanding environments.

Q: What is the ordering process for bulk quantities and can I request a sample before placing a large order?

A: A minimum order quantity of 50 pieces is required. Samples can be requested for testing before making a bulk purchase, ensuring product suitability for your requirements.

Q: How does the leak-proof design benefit my operations?

A: The leak-proof configuration, combined with rigid body and precise sealing, prevents fluid or gas leakage, maintaining system integrity and reducing downtime.
